Ssm DP5-TF

SSM DP5-TF winding machine Man. year - 2013 No. of winder - 40 M/s sides - Single side Denier range - 300 to 1600 Mechanical speed - up to 1500 m/min Heater - For Draw, Godet type , 4 godet per positions, Godet diameter 4 inch , For stabilisation , Hot tube type length 1.6 meter. Types of winding - DIGICONE® or precision, Auto doffing & manual Paper tube feed. Final package paper tube length - 282 mm Package shape - freely programmable on cylindrical tube Traverse length - 100…250 mm infinitely variable Take-up package diameter - up to 300 mm Package weight - up to 8 kg No of Ply - up to 4 ends Supply packages (creel) – package diameter up to 400 mm, tube length up to 320 mm Reserve Creel - Available Fibre material / Fibre structure - PES, PA, PP, PBT, PTT, Glass (other yarns on request) / POY, FDY/FOY Jet Type - Hebarlin Jet as per denier range Positions and Feeders - individually driven and controlled Electrical power (basic power supply) - 400 V, 50 cycles, 3 phases, loadable neutral power line, ground Installed power DP5-TF,Feeding motors 2 x 230 W, 4 x 440 W, 1 x 260 W; heated godets 1.1 kW each; Water consumption - max. 4 litres per position and hour Recommendation for compressed air / process air requirement - compressor with a capacity of up to 30 m3 per position and hour with air dryer, oil filter and air tank (~ 3 m3), process air requirement 12 bar Process air consumption - depending on type of jet and texturing parameters, according indication of jet manufacturer Compressed air for machine operation parameter
